General
Model Number
TCK-69-SD
Series
TC Style
Body Information
Body Material
Basswood with Maple Top
Body Shape
TC Style
Body Finish
Sealed Unfinished
Neck Information
Neck Material
Maple
Neck Shape
Modern C
Neck Finish
Unfinished
Scale Length
25.5" / 648mm
Fingerboard Material
Maple
Fingerboard Radius
12"
Number of Frets
21
Frets
Medium Jumbo, Nickel Silver
Nut Material
Plastic
Nut Width
42mm
Position Inlays
Acrylic Dot
Truss Rod
2-Way-Action
Truss Rod Nut
4 mm Hex
Hardware & Electronics
Finish
Chrome
Pickup Configuration
S-S
Pickups
Ceramic Pickups
Pickguard
3-Ply White - WBW
Controls
1V, 1T, 3-Way Toggle
Bridge
Top Loading TC Bridge
Tuning Machines
Schaller Type
Potentiometers
Full Sized Pots
Misc
Solderless wiring, Includes all mounting screws, strap buttons, and plates
Accessories
Includes
Hex Adjustment Keys & Instrument Cable
sandersk641 –
I really enjoyed putting this kit together! All parts fitted nicely and all drilling accurate. I loved the maple top but the cheaper body was 3 piece and not very attractive. I stained the body and neck with Danish oil. The edge on body I used brown leather spray paint then used 5 coats of clear spray lacquer. I made some mistakes but Im happy. It looks great from 5 ft away! I gave it a good setup with Elixer 10 Guage strings. Electronics are great. The tone and sustain is awesome! I’m vary happy.
dlkessler5 –
Kinda got gob smacked opening up this offering. B stock item with flaws unidentified. Wilkinson bridge with brass barrels. Neck with a flame maple fret board on the near side of stunning. The solderless wiring was a little troubling. One connection had to be soldered because disconnection was required prior to assembly and assembler abused power. I upped to the Wilkinson vintage style tuners to keep with the theme and used some left over tiger eye house paint on the body. I sanded a little heavier on the areas that may have had excessive wear since 1969. This gave a thought to the used not abused theme exposing some bare wood. It got about 3 coats of polycrylic water based satin finish. The thing has its own beauty. I opted for 10-48 ghs strings and the thing just plays and sings like butter. I bought to sell but now have a crush on it.
